New Development On Safety Goggles

We recently are developing HDMI to audio splitter. This is a high-performance, multi-functional HD Audio Extractor, which can extract the audio signal among the HDMI signal to the power
Detailed


We recently are developing HDMI to audio splitter. This is a high-performance, multi-functional HD Audio Extractor, which can extract the audio signal among the HDMI signal to the power amplifier system to obtain high-quality audio effects which is hard for TV speaker to achieve.


Features:

Convert 1 HDMI Input to 1 HDMI + 1 Audio

(SPDIF) Output +3.5mm Analog Audio Output

Input Resolution: Up to 3840x2160@30Hz; 4096@2160@30Hz.

HDMI to achieve the synchronization of audio signal seperation. There are 2.0CH / 5.1CH two kinds of audio mode options.

LED clearly indicate the working state of the Extractor.

Suitable for various HDMI source devices like Roku or Chromecast without dedicated audio output as well as Blu-ray/ DVD/ HD player, cable/satellite box, Amazon Fire TV, Apple TV, PS3/4, Xbox, PC/laptop, HD camera, HD DVR etc.


Specification:

Input Port: 1 x HDMI IN, 1 x USB Power Port

Output Port: 1 x HDMI OUT, 1 x SPDIF (Optical), 1 x 3.5mm Analog Audio output

HDMI Resolution: 2160p@30Hz/1080p@50/60Hz/1080i/720p/1576i/480p/480i

HDMI Version: HDMI1.4b

Support Video Color Format: 24bits/ deep color 30bit, 36bit

Max bandwidth: 340MHz

Max baud rate: 10.2Gbps

Max working current: 340mA
